Aluminum Universal Terminal, 1 Hole, 14-1/0 AWG (Str), 1/4" Stud, Al/Cu Rated, Tin Plated – Electrical Terminal Connector

This aluminum universal terminal is designed for use with both aluminum and copper conductors, accommodating wire sizes from 14 AWG to 1/0 AWG stranded conductors. It features a single hole for a 1/4" stud and is tin plated for enhanced corrosion resistance. Suitable for electrical distributors and switchgear suppliers, this terminal provides a reliable connection point in wire and cable applications within lighting solutions and electrical distribution systems.

Specifications

• Material: Aluminum
• Finish: Tin Plated
• Connection Type: Terminal
• Application: For Aluminum And Copper Conductors
• Number of Conductors: 1
• Conductor Range: 14-1/0 AWG (Stranded)
• Stud Hole Size: 0.27 inches
• Width: 0.63 in
• Product Weight: 0.0340 lbs
• Manufacturer Part Number: KA25U
• Country of Origin: Mexico

Features

• Al/Cu rated for compatibility with aluminum and copper conductors
• Tin plating provides corrosion resistance and durability
• Single screw connection for secure conductor attachment
• UL Listed to UL486A-486B for aluminum and copper conductors at 90°C
• CSA Certified to C22.2, No. 65 for indicated conductor range
• Recommended tightening torque: 50 in.lbs (6 N·m)
• Not recommended for use in highly corrosive environments
