Aluminum Multiple Tap Connector, Clear Insulated, 2 Port, 2 Sided Entry, 14-4 AWG, Al/Cu Rated - Multi Tap Connector

This aluminum multiple tap connector is designed for indoor electrical applications involving copper or stranded aluminum conductors. It features a clear plastisol insulation for visual confirmation of proper conductor insertion, making it suitable for electrical distributors and lighting solutions requiring reliable wire and cable connections. The connector supports a conductor size range of 14-4 AWG and is Al/Cu rated for compatibility with both aluminum and copper conductors.

Specifications

• Material: Aluminum
• Insulation Type: Plastisol
• Conductor Size: 14-4 AWG
• Connection Type: Multi Tap
• Number of Ports: 2
• Voltage Maximum: 600 V
• Width: 1.50 in (38 mm)
• Height: 1.25 in (31.8 mm)
• Length Overall: 1.08 in (27 mm)
• Number of Screws: 2
• Insulation: Yes
• Made in USA: Yes
• Manufacturer: Burndy
• Manufacturer Part #: BIBD42
• Industry Standards: UL 486A-486B, CSA Approved, UL Listed
• RoHS Compliance Status: CM

Features

• Clear plastisol-covered AL6061-T6 aluminum body reduces installation time and eliminates taping
• Clear insulation allows visual confirmation of proper conductor insertion
• Pre-installed oxide inhibitor prevents moisture and contaminants from entering the contact area
• Range-taking capability reduces the number of connectors needed in inventory
• Allen screw type for secure connections
