Aluminum Multiple Tap Connector, Clear Insulated, 12 Port, 2 Sided Entry, 4 AWG-600 kcmil, Al/Cu Rated - Multi Tap Connector

This aluminum multiple tap connector is designed for indoor electrical applications requiring reliable wire and cable connections. Featuring a clear plastisol insulation and a 12-port, two-sided entry design, it supports conductor sizes from 4 AWG to 600 kcmil for both copper and stranded aluminum conductors. Suitable for electrical distributors and switchgear suppliers, this connector facilitates efficient multi-tap connections while ensuring visual confirmation of conductor insertion.

Specifications

• Manufacturer: Burndy
• Manufacturer Part #: BIBD60012
• Material: Aluminum (AL6061-T6)
• Insulation Type: Plastisol
• Connection Type: Multi Tap
• Number of Ports: 12
• Conductor Size Range: 4 AWG - 600 kcmil (Copper and Aluminum)
• Voltage Rating: 600 V Maximum
• Dimensions: 15.53 in (L) x 3.00 in (W) x 2.75 in (H)
• Weight: 3.02 lbs
• Temperature Rating: 194°F
• Certification: UL Listed, CSA Approved, RoHS Compliant
• Country of Origin: United States

Features

• Clear plastisol insulation allows visual confirmation of proper conductor insertion
• Oxide inhibitor pre-installed to prevent moisture and contaminant ingress
• Range-taking capability reduces inventory needs by accommodating multiple conductor sizes
• Clear plastisol covered aluminum body eliminates the need for taping and lowers installation time
• Allen screw type for secure and reliable connections
• Made in USA
