Aluminum Long Barrel 1 Hole Compression Lugs 4 Awg - 3/8 Stud | Compression Connector

This Aluminum Long Barrel 1 Hole Compression Lug is designed for use with copper or aluminum cables, providing a reliable electrical connection for wire and cable applications. Manufactured by Morris Products, it is suitable for electrical distributors and switchgear suppliers seeking durable, high conductivity connectors for lighting solutions and general electrical installations.

Specifications

• Material: 6061-T6 Aluminum
• Wire Size: #4 AWG (per catalog series)
• Stud Size: 3/8 inch
• Inside Diameter: 0.25 inches
• Outside Diameter: 0.44 inches
• Temperature Rating: 90°C
• Voltage Rating: 35 kV
• UL Certification: UL486B AL9CU
• cUL: Yes
• RoHS Compliant: Yes
• Color: Green
• Product Weight: 0.0360 lbs
• Material Treatment: Electro-Tin Plated

Features

• Manufactured from high strength, high conductivity seamless aluminum
• Electro-tin plated for enhanced corrosion resistance
• AL9CU dual rated for use with copper or aluminum conductors
• Oxide inhibitor filled and capped barrel to prevent oxidation
• Color coded and marked with die size and crimp marks for easy identification

Downloads & Links

• Spec Sheet
