Specifications

• Height: 1.74 in | 44.196 mm
• Length: 4.625 in | 117.475 mm
• Weight: 1.27976120341566 lbs
• Width: 4.663 in | 118.4402 mm

Dimensions

• Height BX (IN): 3.75
• Height (mm): 44.196
• Length (mm): 117.475
• Weight BX (LB): 7.5399
• Width BX (IN): 6.5
• Width (mm): 118.4402

Additional Technical Specifications

• Conductor Type: Stranded

Additional Class Attributes

• Barrel Marking: Ink
• ILSCOs Die Index Number: KR

Material and Finish

• Conductor Material: Copper, Aluminum
• Connector Finish: Tin
• Material: Aluminum

Environment and Temperature

• Temperature Rating: 90°C

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 1000 kcmil COMPACT - 600 kcmil
• Conductor Range AL Stranded (Secondary, tap, load): 600 kcmil - 350 kcmil
• Conductor Range CU Stranded (Primary, run, main, line): 750 kcmil - 600 kcmil
• Conductor Range CU Stranded (Secondary, tap, load): 600 kcmil - 350 kcmil

Color

• Color: Silver
• Color Code: Yellow

Voltage

• Voltage Rating: 35 kV

Testing Standards

• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E158587

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 5
• Direct Burial: No
• Dual Rated: Yes
• NEMA Code: S-588-1
• UPC Code: 78366900420
