ALLIED 807939 2-1/2 10FT Tubing - Electrical Metallic Tubing (EMT)

The ALLIED 807939 2-1/2 10FT Tubing is a durable electrical metallic tubing designed for use in electrical distribution systems. It provides mechanical protection for conductors and is suitable for applications requiring reliable conduit solutions. This product is ideal for electrical distributors and switchgear suppliers looking for a robust conduit option within lighting solutions and wire and cable installations.

Specifications

• Product Weight: 2.1600 lb
• Length: 10 ft (3.05 m) with a tolerance of ±0.25 in (6 mm)
• Trade Size: 2-1/2 inch (63 mm)
• Outside Diameter: 2.875 in (73.03 mm)
• Nominal Wall Thickness: 0.072 in (1.83 mm)
• Manufacturer Part #: 807939
• UPC: 091111150432

Features

• Constructed from hot galvanized steel for long-lasting exterior protection
• Compatible with Kwik-Fit® and Kwik-Fit® Compression EMT systems for faster installation
• Provides excellent mechanical protection for electrical conductors
• Ductility allows for easier bending and installation
• Meets ANSI C80.3 manufacturing standards
• Listed to UL Safety Standards 797 and 514B

Downloads & Links

• Spec Sheet
