ALED4T125SFNK/BL
SKU: #116136
Part: #ALED4T125SFNK/BL
UPC: 019813828312
ALED4T125SFNK/BL
SKU: #116136
Part: #ALED4T125SFNK/BL
UPC: 019813828312
Next day delivery
Description
ALED4T125SFNK/BL LED Area Light for Lighting Solutions
The ALED4T125SFNK/BL is a high-performance LED area light designed for outdoor lighting applications such as parking lot perimeter illumination and building side mounting. This product is suitable for electrical distributors and switchgear suppliers seeking reliable, energy-efficient lighting solutions with advanced thermal management and durable construction.
Specifications
- Manufacturer: RAB
- Model Number: ALED4T125SFNK/BL
- Lumens: 15,760 lumens
- Efficacy: 118 lumens per watt
- Input Wattage: 133 watts
- Color Temperature: 4000 kelvins (Neutral)
- Color Accuracy: 71 CRI (Color Rendering Index)
- Lens Material: Tempered Glass
- Ambient Temperature Rating: Up to 104°F (40°C)
- Minimum Starting Temperature: -40°C (-40°F)
- Product Weight: 32 lbs
- IP Rating: IP66 for dust and water protection
- Mounting: Heavy-duty slipfitter mounting arm with stainless steel screws and O-ring seal
- Construction: Die-cast aluminum housing, lens frame, and mounting arm
- LED Lifespan: 100,000 hours (L70) based on IES LM-80 and TM-21 calculations
- IES Classification: Type IV distribution (Forward Throw) for semicircular light distribution
- Surge Protection: 4kV
- Power Factor: 99.4% at 120V, 92.1% at 277V
- THD (Total Harmonic Distortion): 5.4% at 120V, 15.5% at 277V
Features
- Bi-Level Operation allowing 50% and 100% output modes
- Superior thermal management with external "Air-Flow" fins for enhanced heat dissipation
- Specular vacuum-metallized polycarbonate reflector for optimized light distribution
- High-temperature silicone gaskets ensuring environmental sealing
- Mercury and UV free; RoHS-compliant components supporting green technology
- 66% energy cost savings compared to traditional HID lighting
- Five-year warranty covering light output, color stability, driver performance, and fixture finish
- UL Listed for wet locations
- DLC Listed, eligible for utility rebates
- Buy American Act (BAA) compliance available upon request
