ALED4T105Y
SKU: #108026
Part: #ALED4T105Y
UPC: 019813938066
ALED4T105Y
SKU: #108026
Part: #ALED4T105Y
UPC: 019813938066
Next day delivery
Description
ALED4T105Y LED Area Light by RAB
The ALED4T105Y is a high-performance LED area light designed for outdoor illumination, suitable for use by electrical distributors and lighting solutions providers. This fixture is ideal for mounting on building sides, walls, and parking lot perimeters, delivering efficient and reliable lighting with a Type IV light distribution. It offers energy-efficient performance with a long lifespan, making it a practical choice for wire and cable installations and switchgear suppliers seeking durable outdoor lighting solutions.
Specifications
- Manufacturer: RAB
- Input Wattage: 108 watts
- Lumens: 12,971 lumens
- Efficacy: 119 lumens per watt
- Color Temperature: 3000 kelvins (Warm)
- Color Accuracy: 71 CRI
- Lens Material: Tempered Glass
- Ambient Temperature Rating: Up to 104°F (40°C)
- Minimum Starting Temperature: -40°C (-40°F)
- Product Weight: 32 lbs
- Mounting: Universal mounting arm with round pole adaptor included
- Housing: Die-cast aluminum housing, lens frame, and mounting arm
- Reflector: Specular vacuum-metallized polycarbonate
- Gaskets: High-temperature silicone
- LED Lifespan: 100,000 hours (L70)
- UL Listed: Suitable for wet locations
- DLC Listed: Eligible for rebates (DLC Product Code: P0000177F)
- Ingress Protection: IP66 (dust and water resistant)
- Power Factor: 99.6% at 120V, 94.5% at 277V
- Total Harmonic Distortion (THD): 7.6% at 120V, 16.2% at 277V
- Surge Protection: 4kV
- BUG Rating: B1 U0 G2
Features
- Type IV light distribution optimized for side-of-building and parking area illumination
- Superior thermal management with external "Air-Flow" fins
- Universal mounting arm compatible with hole spacing from 1" to 5 1/2"
- Round pole adaptor included for poles with diameters greater than 4"
- Mercury and UV free, RoHS-compliant components for green technology compliance
- 66% energy cost savings compared to 320W metal halide equivalents
- 100,000-hour LED lifespan based on IES LM-80 and TM-21 calculations
- Compatible with round poles 2.5" to 6" diameter
- 5-year warranty covering light output, color stability, driver performance, and fixture finish
