AL3300 Divider
SKU: #393003
Part: #AL3300D5US
UPC: 786776180909
AL3300 Divider
SKU: #393003
Part: #AL3300D5US
UPC: 786776180909
Next day delivery
Description
AL3300 Divider - Aluminum Raceway System
The AL3300 Divider from Wiremold is a component of the AL3300 Series Aluminum Raceway System designed for commercial electrical and communication wiring applications. It provides a compact and effective method to separate and route power and communication cabling in environments such as laboratories, healthcare facilities, and upscale offices. This system supports installation as baseboard, surface-mounted, or under laboratory reagent shelves, offering easy access and modification through its two-piece raceway design. It is suitable for electrical distributors and lighting solutions providers seeking reliable wire and cable management and switchgear suppliers requiring durable raceway components.
Specifications
- Material: 6063 T6 Aluminum Alloy (raceway base and cover)
- Divider Material: 0.040" (1.0mm) galvanized steel
- Wall Thickness: 0.078" (1.99mm) for raceway
- Anodized Finish Thickness: 0.004" (0.004mm)
- Dimensions: Raceway cross-section 2 7/8" (73mm) width x 1 7/8" (48mm) height
- Made in USA
- Manufacturer Part #: AL3300D5US
Features
- Snap-together aluminum extrusions with satin anodized finish for corrosion resistance and ease of maintenance
- Field-installed divider creates dual wiring channels to separate power and communication cabling
- Low-profile design adaptable to baseboard, surface, or under-shelf mounting
- Accommodates most electrical wiring devices and full-size communication faceplates, including single, duplex, NEMA-Locking, GFCI, and surge protection outlets
- Two-piece raceway design enables wiring accessibility and easy circuit modifications
- UL and cUL Listed Raceway and fittings, compliant with NEC Article 386 and CEC Section 12-1600
- Meets UL5 and ADA compliance for installation
- Compact size allows use in limited space environments
