AJF26QT Area Light by RAB - Outdoor Lighting Solutions

The AJF26QT is a durable area light designed for outdoor applications, ideal for electrical distributors and lighting solution providers seeking reliable lighting fixtures. Manufactured by RAB, this fixture features a die cast aluminum housing and door, providing robust construction suitable for wet locations. It is optimized for use at mounting heights between 10 and 15 feet, delivering efficient illumination with a lamp output of 1,800 lumens and an efficacy of 62 lumens per watt. This product is well-suited for wire and cable installations requiring dependable switchgear and lighting components.

Specifications

• Manufacturer Part #: AJF26QT
• Input Wattage: 29 watts
• Lumens: 1,800 lumens
• Efficacy: 62 lumens per watt
• Construction Type: Die Cast Aluminum
• Product Weight: 13.8 lbs
• Socket Type: CFL Plug in type, GX24q-4 base
• UL Listed: Suitable for wet locations
• Effective Projected Area (EPA): 0.8 (1.5 with house-side shield)

Features

• Heavy duty die cast aluminum housing and door for durability
• Hydroformed semi-specular aluminum reflector for optimized light distribution
• Silicone gasket seals optical compartment to protect internal components
• 4kV pulse rated socket for electrical reliability
• Sleek design with low effective projected area (EPA) for reduced wind load
• Includes lamp with 12,000 hours rated life

Downloads & Links

• Instructions
• Spec Sheet
