Features

• Allows Easy Insertion of Grounding Conductor for Through or End Connection
• Low Grounding Connector Profile
• Spring Action Design Maintains Positive Firm Contact on Grounding Conductor
• Set Screw Provides Fixed Alignment and Positive Ground Continuity
• Phenolic Insulation, with 150 Deg C UL Rating, Molded on Over Metallic Conduit Stop will Not Shatter or Shrink at Sub-Zero Temperatures

Additional Information

• Applicable Standard W-F-408E, NEMA FB-1

Specifications

• Type: Threaded, Set Screw
• Trade Size: 3 Inch
• Wire Size: 8 AWG Solid/Stranded to 2/0 AWG Stranded
• Lug Type: Lay-In, Tin Plated Copper Saddle
• Conductor Material: Copper/Aluminum
• Throat Type: Phenolic Insulated
• Diameter: 4 Inch
• Height: 1 Inch
• Material: Aluminum Body, Stainless Steel Screw
• Approval: UL 467/514B, CSA 22.2
• Used On: Threaded Rigid Conduit/IMC
• Series/Model: ABLG
