97407 Wallplate Stainless Steel 430 Satin Finish

The 97407 Wallplate by Mulberry Metal Products is a 7-gang, standard size metallic finish wallplate designed for electrical distributors and lighting solutions applications. It is specifically engineered to accommodate (7) block duplex/GFI openings, making it suitable for residential, commercial, and institutional installations requiring durable wire and cable protection and switchgear supplier compatibility.

Specifications

• Manufacturer Part #: 97407
• Material: 0.03 Inch Thickness 430 Stainless Steel
• Finish: #4 Fine Satin
• Gang: 7
• Size: Standard (4.5 in. high x 13.625 in. wide)
• Opening: (7) Block Duplex / GFI
• Mounting: Device (3.812 in. between mounting holes)
• Certification: UL Listed (UL 514D)

Features

• Good corrosion resistance suitable for industrial and commercial applications in less corrosive atmospheres
• Smooth, rounded edges to prevent wall damage
• Comes with 5/16 inch standard slotted 6-32 oval head screws in matching finish
• Can be silk-screened or engraved for customization
• Made in the U.S.A.
