90° Liquidtight Connector with Copper Grounding Lug 1"
SKU: #175149
Part: #493CSGR
UPC: 751338031067
90° Liquidtight Connector with Copper Grounding Lug 1"
SKU: #175149
Part: #493CSGR
UPC: 751338031067
Next day delivery
Description
90° Liquidtight Connector with Copper Grounding Lug 1" – Liquidtight Conduit Fitting
The Southwire 90° Liquidtight Connector with Copper Grounding Lug 1" is designed to connect liquidtight conduit and provide termination for an external bonding conductor running parallel to the conduit. This fitting is ideal for electrical distributors and switchgear suppliers requiring durable, UL-listed liquidtight flexible metal conduit fittings suitable for hazardous locations. It is constructed from malleable iron with a zinc electroplated finish to ensure corrosion resistance and durability, incorporating an insulated throat to protect conductors from abrasion.
Specifications
- Conduit Size: 1"
- Material: Malleable Iron
- Finish: Zinc Electroplated
- Grounding Lug: Copper Lay-In
- Product Weight: 0.7225 lbs
- UL Listings: UL 467, UL 486A
- Compliance: NEC 501-4(b), 502-4(a), (2)503-3(a) Class 1 Div.2, Class II Div.1 and 2, Class III Div.1 and 2, NEC 351-I
Features
- Liquidtight, raintight, and oiltight fitting
- Copper lay-in grounding lug for external bonding conductor termination
- Insulated throat protects conductors from abrasion damage
- Zinc electroplated finish for enhanced durability
- Suitable for grounding sizes 3/8" through 1-1/2"
