76401 Wallplate - Painted Metal Electrical Wallplate

The 76401 Wallplate by Mulberry Metal Products is a 1-gang, princess size wallplate designed for block duplex and GFI receptacles. It is constructed from 0.03 inch thickness cold-rolled steel with a smooth semi-gloss white powder coat finish. This wallplate is suitable for residential and commercial electrical distributor applications, providing durable and reliable protection for electrical wiring and devices.

Specifications

• Manufacturer: Mulberry Metal Products
• Manufacturer Part #: 76401
• Material: 0.03 Inch Thickness Cold Rolled Steel
• Color: White
• Finish: Smooth Semi-Gloss
• Size: Princess (5 in. high x 2.75 in. wide)
• Gang: 1
• Opening: Block Duplex / GFI
• Mounting: Device (3.812 in. between mounting holes)
• Product Weight: 0.1200 lbs
• UPC: 095327764018
• Standards: UL 514D
• Certification: UL Listed

Features

• Ideal for residential and commercial applications
• Smooth rounded corners for a traditional look and to prevent wall damage
• 1/2 inch taller height to cover gaps or holes between sheetrock and electrical boxes
• Made from premium steel alloy with a durable powder coat finish to inhibit oxidation, chipping, and scratching
• Can be field painted to match new room décor if needed
• Comes with 5/16 inch standard slotted 6-32 oval head screws in matching finish
• Made in the U.S.A.
