Specifications

AC Horsepower Ratings

• At Rated Voltage: 1 HP

Electrical Specifications

• Grounding: GFCI Ground Fault
• Amperage: 15 Amp
• Voltage: 125 Volt
• Pole: 2
• Wire: 3
• Current Limiting: 10kA
• Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
• Trip Level: 5mA plus or minus 1mA

Environmental Specifications

• Flammability: Rated V-2 per UL94
• Operating Temperature: -35C-66C

Material Specifications

• Body Material: Polycarbonate
• Cover Material: Nylon
• Strap Material: Galvanized Steel with Riveted Ground Contacts
• Line Contacts: 0.031" thick Brass, Douple Wipe
• Internal Switch Contacts: Silver Alloy
• Terminal Screws: Plated Brass
• Grounding Screw: Plated Steel
• Clamp Nuts: Galvanized Steel
• Color: Black

Mechanical Specifications

• Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
• Terminal Accom.: 14-12 AWG
• Product ID: Ratings are permanently marked on device
• Termination: Back & Side 20A Feed-Thru

Product Features

• NEMA: 5-15R
• Color: Black
• Country of Origin: China

Standards and Certifications

• NEMA: WD-1 & WD-6
• ANSI: C-73
• UL943 Class A: File E48380
• UL498HG: File E13399
• CSA C22.2 No. 42: File LR-57811
• NOM: 057
• Warranty: 2-Year Limited
