71533 Flat Panel Floodlight Fixture - LED Flood Lighting

The 71533 Flat Panel Floodlight Fixture by Morris Products is a 50-watt architectural flood and spot luminaire designed for durable outdoor lighting applications. This fixture features a 1/2" knuckle mount and is constructed with an aluminum housing and tempered glass, making it suitable for wet locations. It is ideal for electrical distributors and lighting solutions providers seeking reliable, high-efficiency floodlighting for commercial or industrial environments.

Specifications

• Manufacturer: Morris Products
• Model Number: 71533
• Wattage: 50 watts
• Mounting Type: 1/2" Knuckle Mount
• Housing Material: Aluminum with Tempered Glass
• Finish: Bronze
• Input Voltage: 100-277 VAC, 50/60 Hz
• Input Current: 0.38 A Max
• Power Factor: ‚â• 0.92
• Luminous Flux: 6,179 lumens
• Luminous Efficacy: 126.31 lm/W
• Color Temperature: 5000K
• CRI: 82.6
• Beam Angle: 90¬∞ x 120¬∞
• Driver Efficiency: 89%
• LED Manufacturer: Philips Lumileds
• LED Type: LUXEON 3030
• LED Quantity: 30 pcs
• IP Rating: IP65, suitable for wet locations
• Operating Temperature Range: -20¬∞C to +55¬∞C
• Storage Temperature Range: -40¬∞C to +80¬∞C, 10‚Äì90% RH
• Weight: 5.0 lbs
• Warranty: 5 years

Features

• High-efficiency LED floodlight delivering over 6,000 lumens for bright, uniform illumination
• Durable aluminum housing with bronze finish and tempered glass lens for enhanced weather resistance
• Wide operating voltage range (100-277 VAC) compatible with various electrical systems
• Integrated LED driver with high power factor and low total harmonic distortion (THD)
• Designed for easy installation with included 1/2" knuckle mount bracket
• Certified to UL1598, UL8750, and other safety and electromagnetic compatibility standards
• Suitable for commercial and industrial outdoor lighting applications requiring reliable floodlighting
• RoHS compliant and DLC listed for energy efficiency and quality assurance

Downloads & Links

• Catalog
• Specification/Technical
