Features

• Recessed 7-Gang Round Cover Floorbox
• For Use In Concrete Floors
• 4.08" Minimum Depth of Pour
• Box Includes Installation Cover
• Accepts industry Standard Size Wallplates
• Semi Adjustable

Specifications

• Country of Origin: United States
• Application - For Use On: Concrete
• Dimensions: 10 in x 12.08 in x 4.08 in
• Width: 12.700 in
• Each - Width: 12.700 in
• Industry Standard(s): UL/CSA;UL514
• Mounting Method: Cast Into Concrete
• Application: For Use in Concrete Floors
• Cable Entry: Through Cover
• Color: Metallic
• Height: 4.08 in
• Knockouts: 11) 1" - 1 1/2" , 1) 2"
• Length: 10 in
• Size: 10 in x 12.08 in x 4.08 in
• Special Features: Semi Adjustable
• Standard: UL/CSA;UL514
• Type: 7-Gang Recessed Floor Box
• Description - Invoice: REC FB, 7-GANG, 4-IN DEEP, AV STYLE
• Freight Class Code: 06168002
• Harmonization Code: 7326908688
• Image Actual Or Representative: A
• MSDS Flag: No
• Construction: Fabricated
• Material: Pre Galvanized Steel
• Number of Gang(s): 7-Gang
• Series: Recessed Rectangular - CFB Series
• Base Unit of Measure: EA
• BOX SIZE: 5.000x14.800x12.700 (in)
• Carton - SCC-14 Next Lower Level Sub Pack: 00783585315881
• Case Weight: 14.900 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each
• Pallet Height: 45.000 in
• Pallet Length: 48.000 in
• Pallet Weight: 1341.000 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: No
