694-B Industrial Panel Mount Pushbutton – Electrical Distributor Pushbutton Switch

The 694-B Industrial Panel Mount Pushbutton by Edwards Signaling is a low voltage, snap-fit pushbutton designed for integration into electrical distributor systems, lighting solutions, wire and cable assemblies, and switchgear applications. This protruding center pushbutton is engineered for reliable momentary contact switching in AC or DC circuits up to 48 volts, making it suitable for industrial control panels and signaling devices.

Specifications

• Manufacturer: Edwards Signaling
• Model Number: 694-B
• Mounting Type: Snap Fit
• Center Type: Protruding
• Switching Voltage: AC/DC up to 48 volts
• Current Ratings: 12V AC - 10.0 A, DC - 4.0 A; 24V AC - 10.0 A, DC - 2.0 A; 48V AC - 5.0 A, DC - 1.0 A
• Contact Type: Normally open momentary contacts
• Shell Material: Polished, anodized aluminum
• Button Back Material: Zytel 101 nylon
• Color: Black
• Mounting Hole Diameter: 5/8" (16mm)
• Approximate Net Weight: 0.02 lb (9 g)

Features

• Durable phosphor bronze contact spring with long-duration wiping action for reliable electrical contact
• Snap-fit mounting for quick and secure installation in panel applications
• Protruding button design for easy actuation
• Compatible with 147-1 mounting plate accessory for enhanced panel integration
• Suitable for low voltage control circuits in industrial and commercial electrical systems

Downloads and Links

• Product Catalog PDF - Push Buttons Low Voltage 600 Series (Pages 7-14 and 7-15)
• Mounting Plate 147-1 Specification Sheet
