55054, Straight Blade Power Single Receptacle - Industrial Grade Electrical Distributor Component

The Leviton 55054 is a 30 amp, 125/250 volt, NEMA 14-30R straight blade power single receptacle designed for surface mounting. It is engineered for industrial-grade applications requiring reliable grounding and robust electrical connections. This receptacle is suitable for use by electrical distributors and switchgear suppliers in wiring and lighting solutions requiring safe and durable power outlets.

Specifications

• Manufacturer: Leviton
• Manufacturer Part #: 55054
• Amperage: 30 amperes
• Voltage: 125/250 VAC
• NEMA Configuration: 14-30R
• Number of Poles: 3
• Wire: 4
• Horsepower Rating: 2 horse power
• Grounding: Grounding
• Dielectric Voltage: Withstands 2000 volts per UL 498
• Operating Temperature: -40°C to 60°C
• Body Material: Thermoplastic
• Face Material: Thermoplastic
• Color: Black
• Flammability Class: Rated V-2 per UL 94
• Product Weight: 0.83 lbs

Features

• Industrial-grade construction with durable thermoplastic body and face
• Heavy-gauge, double-wire copper alloy contacts for reliable conductivity
• Side wired with steel strap for secure mounting
• Terminals with ID markings for correct and speedy wiring
• Supports wire sizes up to 4 AWG
• Temperature rise limited to a maximum of 30°C after 50 cycles overload at 150% rated current
• Meets ANSI C-73, CSA C22.2 No. 42, NEMA WD-6, NOM 057, and UL 498 standards
• 10-year limited warranty
