Specifications

Material Specifications

• Color: Black
• Line Contacts: Brass Double-Wipe
• Body Material: Nylon
• Face Material: Nylon
• Strap Material: Galvanized Steel

Standards and Certifications

• Warranty: 10-Year Limited
• NOM: 057
• CSA C22.2 No. 42: File 152105
• UL498: File E13399
• ANSI: C-73
• NEMA: WD-6

Electrical Specifications

• Amperage: 50 A
• Wire: 3
• Dielectric Voltage: Withstands 2000V per UL498
• Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
• Pole: 2
• Current Limiting: Full Rated Current
• Voltage: 125 VAC
• Grounding: Grounding

Product Features

• Amperage: 50 A
• NEMA: 5-50R
• Color: Black
• Country Of Origin: Please Contact Customer Service.
• Device Type: Power Device
• Voltage: 125 VAC

Mechanical Specifications

• Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
• Product ID: Ratings are permanently marked on device
• Terminal Accom.: Up to 4 AWG

AC Horsepower Ratings

• At Rated Voltage: 2 HP

Environmental Specifications

• Flammability: Rated V-2 per UL 94
• Operating Temperature: -40°C to 60°C
