4X4X6 Schedule 40 PVC Junction Box – Electrical Enclosure

The 4X4X6 Schedule 40 PVC Junction Box by Southwire is a surface-mounted enclosure designed for electrical distributors and lighting solutions requiring secure wire splices and conduit connections. Made from durable PVC, this junction box is fabricated to ensure safety and longevity during installations. It is suitable for applications where multiple conduits need to be connected, offering flexibility without entrance hubs. This product is relevant for wire and cable management and is ideal for use by switchgear suppliers and electrical contractors.

Specifications

• Material: PVC
• Dimensions (Inside): 4" x 4" x 6"
• Product Weight: 1.5 lbs
• Manufacturer: Southwire
• Manufacturer Part #: 1223
• UPC: 751338232624
• NEMA Enclosure Ratings: Type 1, 3, 3S, 4, 4X, 5, 6, and 6P
• Knockouts: None

Features

• NEMA 3 rated enclosure where indicated
• Surface-mounted design without entrance hubs for multiple conduit connections
• Allows wire splices to be made within the enclosure
• Suitable for concrete encasement or burial (not guaranteed watertight in all conditions)
• Fabricated for optimal safety during electrical installations
• Screws are zinc plated steel for corrosion resistance

Downloads & Links

• Spec Sheet
