3M 5302 3M MOTOR LEAD PIGTAIL SPLICE 5302, 1 KV, 1-HOLE LUG CONNECTION, FEEDER:2-1/0 AWG , MOTOR LEAD: 4-1/0 AWG , 1/CASE
SKU: #409279
Part: #5302
UPC: 054007122647
3M 5302 3M MOTOR LEAD PIGTAIL SPLICE 5302, 1 KV, 1-HOLE LUG CONNECTION, FEEDER:2-1/0 AWG , MOTOR LEAD: 4-1/0 AWG , 1/CASE
SKU: #409279
Part: #5302
UPC: 054007122647
Total Price: $109.53 per each Sold in increments of 1 each
Next day delivery
Description
3M 5302 Motor Lead Pigtail Splice Kit – Electrical Connector for Wire and Cable
The 3M 5302 Motor Lead Pigtail Splice Kit is designed for splicing motor lead cables to incoming feeder cables at voltages of 1000 volts or less. This kit facilitates secure and insulated connections using copper compression, one-hole lugs in a pigtail configuration. It is suitable for electrical distributors and switchgear suppliers requiring reliable splicing solutions for wire and cable in motor lead applications.
Specifications
- Voltage Rating: 1000 V and less
- Cable Type: Single Conductor Cable
- Connection Type: 1-Hole Lugs
- Feeder Cable Wire Range: 2–1/0 AWG
- Motor Lead Cable Wire Range: 4–1/0 AWG
- Maximum Bolt Length: 3/4" (19.1 mm)
- Insulation Outer Diameter Range: 0.34"–0.54" (8.6–13.7 mm)
- Lug Cover Inner Diameter: 0.95" (24.1 mm)
- Lug Cover Length: 4.2" (106.7 mm)
- RoHS Compliant: Yes
- Case Quantity: 1
- Product Weight: 0.6460 lbs
- UPC: 054007122647
- Manufacturer: 3M
- Manufacturer Part Number: 5302
Features
- Includes 3 pigtail lug covers made from EPDM rubber for insulation and moisture sealing
- Contains mastic sealing strips for moisture resistance
- Includes locking pins and tubes of silicone grease to aid installation and enhance sealing (specific to kits 5302–5304)
- Designed for use with copper compression, one-hole lugs (lugs sold separately)
- Kit contents support making three splices per kit
- Compatible with 3M Scotchlok Copper Compression Lugs 30000 Series and other UL-listed copper lugs
