3M 5301 3M MOTOR LEAD PIGTAIL SPLICE 5301, 1 KV, 1-HOLE LUG CONNECTION, FEEDER:10-4 AWG , MOTOR LEAD: 12-4 AWG , 1/CASE
SKU: #409280
Part: #5301
UPC: 054007122630
3M 5301 3M MOTOR LEAD PIGTAIL SPLICE 5301, 1 KV, 1-HOLE LUG CONNECTION, FEEDER:10-4 AWG , MOTOR LEAD: 12-4 AWG , 1/CASE
SKU: #409280
Part: #5301
UPC: 054007122630
Total Price: $83.60 per each Sold in increments of 1 each
Description
3M 5301 Motor Lead Pigtail Splice Kit – Electrical Wire and Cable Connection
The 3M 5301 Motor Lead Pigtail Splice Kit is designed for splicing motor lead cables to incoming feeder cables at voltages of 1000 volts or less. This splice kit is ideal for electrical distributors and switchgear suppliers requiring reliable and insulated connections using one-hole lug configurations. It accommodates feeder cable sizes from 10 to 4 AWG and motor lead cable sizes from 12 to 4 AWG, providing effective insulation and moisture sealing for single conductor cables.
Specifications
- Voltage Rating: 1000 V and less
- Cable Type: Single Conductor Cable
- Connection Type: 1-Hole Lug
- Feeder Cable Wire Range: 10–4 AWG
- Motor Lead Cable Wire Range: 12–4 AWG
- Maximum Bolt Length: 1/2" (12.7 mm)
- Insulation Outer Diameter Range: 0.17"–0.36" (4.3–9.1 mm)
- Lug Cover Inner Diameter: 0.70" (17.8 mm)
- Lug Cover Length: 3.4" (86.4 mm)
- RoHS Compliant: Yes (2011/65/EU)
- Product Weight: 0.4890 lbs
Features
- Main component is a slip-on lug cover made from EPDM rubber for durable insulation
- Includes mastic sealing strips for moisture resistance
- Contains silicone grease tubes to aid installation and improve seal integrity
- Designed for use with copper compression one-hole lugs (lugs sold separately)
- Kit includes materials for making three splices per case
- Suitable for use with 3M Scotchlok Copper Compression Lugs 30000 Series or other UL-listed copper lugs
