30457, Weatherproof Cover - Electrical Weatherproof Cover

The 30457 Weatherproof Cover is designed to protect toggle switches and GFI or duplex receptacles in outdoor environments. It is suitable for use by electrical distributors and lighting solutions providers requiring durable, weather-resistant covers for wire and cable switchgear applications. This cover mounts directly to a 2-gang weatherproof box, providing reliable protection against environmental elements in compliance with local electrical codes.

Specifications

• Manufacturer Part #: 30457
• Color: Gray
• Material: Die-cast zinc lids with aluminum base plate
• Mounting Type: Device Mount
• Gang: 2
• Orientation: Vertical
• Opening: 1 toggle switch opening, 1 GFI opening (also compatible with duplex receptacles)
• Product Weight: 0.7 lbs
• Certification: UL Listed, CSA Certified

Features

• Heavy-duty spring-loaded die-cast zinc covers (lids) for rugged durability
• Superior powder coat paint finish for maximum weatherability and scratch resistance
• Heavy-duty universal gasket and stainless steel mounting screws included for secure installation
• Manufactured in the USA
• Individually packaged with shrink wrap and barcode for efficient inventory management

Downloads & Links

• Specification/Technical
• Catalog
• Other 1
