30272, Weatherproof Outlet Box
SKU: #285989
Part: #30272
UPC: 095327302722
30272, Weatherproof Outlet Box
SKU: #285989
Part: #30272
UPC: 095327302722
Next day delivery
Description
30272 Weatherproof Outlet Box - Die-Cast Aluminum Electrical Box
The 30272 Weatherproof Outlet Box by Mulberry Metal Products is designed for branch circuit wiring in wet, damp, or dry locations. This durable electrical box is suitable for electrical distributors and lighting solutions providers requiring reliable weatherproof enclosures. It is constructed from heavy-duty die-cast aluminum with a powder coat finish to ensure maximum weatherability, making it ideal for outdoor and wet environment applications. The box's compact dimensions and robust design support wire and cable installations while meeting NEMA 3R standards.
Specifications
- Manufacturer: Mulberry Metal Products
- Manufacturer Part #: 30272
- Material: 0.094 Inch Thick Die-Cast Aluminum
- Finish: Powder Coat
- Color: Gray
- Height: 4.5 Inch
- Width: 4.5 Inch
- Depth: 2.0 Inch (from catalog details)
- Product Weight: 1.1 lbs
- UPC: 095327302722
- Listings: c-UL-us Listed (United States and Canada)
- Rating: NEMA 3R
- Country of Origin: Made in the USA
Features
- Suitable for wet, damp, or dry locations
- Heavy-duty die-cast aluminum construction, 0.094 inch thick
- Superior powder coat finish for enhanced weather resistance
- Includes detachable lugs, two close-up plugs, and self-tapping ground screw
- Compact 4.5 in. x 4.5 in. size, suitable for 2-gang wiring applications
- Designed for branch circuit wiring protection in electrical installations
