30263 Weatherproof Box - Die-Cast Aluminum Electrical Enclosure

The 30263 Weatherproof Box by Mulberry Metal Products is a durable, 2-gang electrical enclosure designed for branch circuit wiring in wet, damp, or dry locations. Ideal for electrical distributors and switchgear suppliers, this weatherproof box offers reliable protection for wiring and devices in outdoor or harsh environments. Its rugged construction and multiple outlet locations support versatile applications in lighting solutions and wire and cable installations.

Specifications

• Material: 0.094 Inch Thick Heavy Duty Die-Cast Aluminum
• Color: Gray
• Dimensions: 4.5 Inch Width x 4.5 Inch Height x 2 Inch Depth
• Number of Outlets: 7 threaded 1/2 inch outlets
• Outlet Locations: 2 in each end, 1 in each side, 1 in back
• Cubic Capacity: 30.5 cubic inches
• Certification: c-UL-us Listed
• NEMA Rating: NEMA 3R
• Product Weight: 1.1 lbs

Features

• Rugged die-cast aluminum construction for long-lasting durability
• Superior powder coat paint finish for maximum weatherability and scratch resistance
• Detachable mounting lugs, 2 closure plugs, and a self-tapping ground screw included
• Manufactured in the USA with quality assurance
• Suitable for use as a weatherproof junction box or housing for various electrical devices

Downloads & Links

• Specification/Technical
• Catalog
• Other 1
