30245, Weatherproof Outlet Box - Weatherproof Electrical Enclosure

The 30245 Weatherproof Outlet Box by Mulberry Metal Products is a durable electrical enclosure designed for use in branch circuit wiring in wet, damp, or dry locations. This weatherproof box is suitable for electrical distributors and switchgear suppliers requiring reliable outdoor or indoor protection for wiring and outlets. It features a heavy-duty die-cast aluminum construction with a powder coat painted finish to ensure maximum weatherability and corrosion resistance.

Specifications

• Material: 0.094 Inch Thickness Heavy Duty Die-Cast Aluminum
• Color: Gray
• Dimensions: 4.5 Inch Height x 4.5 Inch Width x 2.0 Inch Depth
• Capacity: 30.5 Cubic Inch
• Number of Gangs: 2
• Number of Hubs: 5
• Hub Size: 1/2 Inch
• Hub Location: 2 in each end, 1 in back
• Enclosure Rating: NEMA 3R
• Approval: UL Listed for Canada and US
• Product Weight: 1.1 lbs

Features

• Weatherproof design suitable for wet, damp, and dry locations
• Heavy-duty die-cast aluminum construction for durability
• Powder coat painted finish for enhanced weather resistance
• Includes detachable lug, self-tapping ground screw, and 2 close-up plugs
• UL listed for use in United States and Canada
• NEMA 3R rated enclosure for outdoor protection
• Compact size optimized for branch circuit wiring applications
• Manufactured in the USA
