3 HOLE PUSHBUTTON ENCL - Pushbutton Enclosure

The Carlon CP300N 3 Hole Pushbutton Enclosure is a non-metallic, 30.5mm (3) hole enclosure designed for standard oil-tight pushbuttons, switches, and pilot lights. Molded from engineered thermoplastic material, it provides resistance to corrosive agents and is suitable for electrical distributors, lighting solutions, wire and cable management, and switchgear suppliers requiring durable and reliable enclosures for control devices.

Specifications

• Material: Thermoplastic (nylon base and cover)
• Hole Size: 30.5mm keyed pushbutton holes
• Mounting: Integrally molded mounting flange
• Screws: 304 (18-8) stainless steel screws, brass screw inserts
• Temperature Range: -40° to 185°F
• Weight: 7.62 lbs
• Standards: UL Listed per UL 50 for industrial controls, UL E108856
• RoHS Compliant
• Country of Origin: Mexico

Features

• High-impact strength and chemical resistance
• High dielectric strength for electrical safety
• Universal pushbutton holes accommodate standard oil-tight pushbuttons, switches, and pilot lights
• Grounding plate included on the cover
• Suitable for conduit entries, junction boxes, MRO, and OEM applications
• UL94-V2 flame retardant rating
