3/4" Rigid Offset Nipples, 3/4" Offset HDG - Malleable Iron | Electrical Conduit Fittings

Topaz’s 3/4" Rigid Offset Nipples are designed for use as offset connectors between two enclosures or raceways, suitable for both indoor and outdoor applications. This product facilitates a 3/4" offset in the axis of EMT conduits, enabling easier direction or slight elevation changes. Manufactured from malleable iron with a hot dip galvanized finish, these rigid conduit fittings are engineered to ensure durability and corrosion resistance, making them a reliable component for electrical distributors and switchgear suppliers.

Specifications

• Material: Malleable Iron
• Finish: Hot Dip Galvanized
• Connection: 3/4 NPSM IN
• Length: 2.75 IN
• Outside Diameter: 1.25 IN
• Product Weight: 0.2765 lbs
• Installation Type: Threaded
• Flexibility: Rigid Conduit
• Application: Indoor, Outdoor, Use as an Offset Connector between Two Enclosures, Raceways

Features

• Enables 3/4" offset in conduit axis for easier routing
• Dip galvanized finish enhances corrosion resistance and product integrity
• Smooth interior surface facilitates wire pulling and reduces abrasion damage
• Threaded NPSM connection ensures secure and reliable installation

Downloads & Links

• Spec Sheet
