Features

• Aluminum construction provides a corrosion resistant installation
• Innovative GOTHCA® ring incorporates a split hinge design to prevent friction and to provide strain relief
• Neoprene grommet
• Knurled compression nut allows the fittings to be hand tightened to UL requirements
• GOTCHA® color-coded ring provides fast identification of cord size
• Additional colors and sizes available

Specifications

• Country of Origin: China
• Buy American Compliant: Contact Manufacturer
• Dimensions: 2.05 in x 1.38 in x 1.38 in
• Width: 1.380 in
• Each - Width: 1.380 in
• Hazardous Rating(s): Class I, Division 2;Class II Division 1 & 2;Class III, Division 1 & 2
• Height: 1.38 in
• Industry Standard(s): UL 514B
• Length: 2.05 in
• Product Type: Commercial Fittings
• Environmental Conditions: Wet Location
• Size: 2.05 in x 1.38 in x 1.38 in
• Standard: UL 514B
• Configuration: Straight
• Connector Type: Strain-Relief
• Trade Size: 3/4 in
• Weight: 0.162 lb.
• ARRA Compliant: Contact Manufacturer
• Class Code: D04
• Description - Invoice: CORDGRIP CONN 3/4 IN (.625-.75) ALUMINUM
• Freight Class Code: 06202000
• Harmonization Code: 7616995190
• Image Actual Or Representative: R
• MSDS Flag: Yes
• Order Multiple: 15 EA
• Returnable Indicator: Yes
• Stock Indicator: S - Shelf Stock
• Sub Class Code: D047D0487
• Cable Range: .625 - .750 in
• Fitting Type: Connectors
• Form Size: 3 in
• Color Code: Yellow
• Conduit Type: Liquidtight
• Material: Aluminum
• Base Unit of Measure: EA
• BOX SIZE: 4x8.75x5 (in)
• Carton - Gross Weight per Pack: 2.43 lb.
• Carton - Number of Sub Packs: 15
• Carton - Pack Description: Carton
• Carton - SCC-14 Next Lower Level Sub Pack: 50169480380
• Carton - Total Units: 15 EA
• Each - Pack Description: Each
• Item Package Type: Carton
• Lowest Level UOM: Each
• Pallet - GTIN - Package: 70050169480389
• Pallet - Number of Sub Packs: 304
• Pallet - Pack Description: Pallet
• Pallet - SCC-14 Next Lower Level Sub Pack: 50050169480385
• Pallet - Total Units: 4560 EA
• Pallet Height: 36.375 in
• Pallet Length: 42.000 in
• Pallet Weight: 783.720 lb.
• Pallet Width: 48.000 in

Certifications

• Certified Listed: UL Listed;CSA Certified
• EU RoHS Indicator: Contact Manufacturer
