Features

• Highest motor load ratings in the industry
• 12 ON/OFF operations per day
• One ON and one OFF tripper included
• Available with pool heater protection
• Teeter-type terminals for multiple load connections

Prop 65

• Please see the Warning @ www.P65Warnings.ca.gov - Lead

Specifications

• Country of Origin: Mexico
• Product Height: 10.125 in; 257.2 mm
• Product Depth: 3.625 in; 92.1 mm
• Operating Temperature Min: -40°F; -40°C
• Operating Temperature Max: 130°F; 54°C
• Warranty Period: 1-Year limited
• Maximum On Off Operations: 12
• Operation Mode: 24 hour
• Applications: Heater Thermostat Control; Motor Control; Pump Control
• Application Compatibilities: LED
• Heater Control Output: 10 A, 250 VAC MAX, 60 Hz
• Wiring Option: Terminals
• Input Voltage Ranges: 120 VAC, 60 Hz
• Number Of Circuits: 1
• Enclosure Type: Outdoor type 3R metal
• Switch Type: SPST
• Power Consumption Max W: 3 W
• Pilot Duty Load Ratings Ranges: 1000 VA, 120-240 VAC, 60 Hz
• PDF Standards And Certifications: cULus; cCSAus; LED

Certifications

• UL Certification: cULus
• CSA Certification: cCSAus
• Other Certifications: LED

Load Ratings

• Pilot Duty Load Ratings: 1000 VA, 120-240 VAC, 60 Hz
• Electronic Ballast Load Ratings: 16 A, 120 VAC
• Electronic Ballast Load Ratings Ranges: 16 A, 120 VAC
• Tungsten Load Ratings: 40 A, 120 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 240 VAC, 60 Hz
• Tungsten Load Ratings Ranges: 40 A, 120-240 VAC, 60 Hz
• Resistive Load Ratings: 40 A, 240 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 120 VAC, 60 Hz
• Resistive Load Ratings Ranges: 40 A, 120-240 VAC, 60 Hz
• Inductive Load Ratings: 40 A, 240 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 120 VAC, 60 Hz
• Inductive Load Ratings Ranges: 40 A, 120-240 VAC, 60 Hz
• Motor Load Ratings Ranges: 2 HP, 24 FLA @ 120 VAC, 60 Hz; 5 HP, 28 FLA @ 240 VAC, 60 Hz

Knockout

• Knockout Dimensions Bottom: (2) 1/2" and 3/4"
• Knockout Dimensions Back: 1/2" and 3/4" combination
