20A Single Pole Toggle Switch, 120/277V, White – Commercial Grade Lighting Control

This 20A Single Pole Toggle Switch is designed for commercial spec grade electrical applications, providing reliable switching control for lighting and electrical circuits. It is side wired only and suitable for indoor dry environments, making it an appropriate choice for electrical distributors and lighting solutions providers seeking durable wire and cable accessories or switchgear components.

Specifications

• Application: Commercial Spec Grade
• Current Rating: 20 amperes
• Voltage Rating: 120-277 VAC
• Number of Poles: Single Pole
• Connection: Side Wired Only
• Material: Nylon
• Color: White
• Mounting: Screw Mount
• Contact Rating: Per UL 20
• Operating Cycles: 50,000 Cycles
• Operating Temperature: Maximum continuous 75°C, minimum -40°C without impact
• Dimensions (W x H x D): 1.49 in x 1.83 in x 4.18 in
• Weight: 0.15 lb
• Contact Configuration: Two Position
• Environmental Conditions: Indoor Dry unless protected by additional means
• Country of Origin: China
• Manufacturer: Hubbell Wiring Device-Kellems
• Manufacturer Part #: CS120W

Features

• Thread cleaning captive mounting screw for secure installation
• Abuse resistant nylon toggle for enhanced durability
• Steel, zinc plated bridge providing corrosion resistance
• Auto grounding mounting bridge made of zinc plated steel
• Silver alloy contacts for reliable electrical performance
• Thermoplastic base and top materials for electrical insulation
• Brass ground screw and terminal screws for secure electrical connections
