20A 125V Hard Use Spec-Grade Tamper-Resistant Half-Controlled Plug Load Decorator Duplex Receptacle, White
SKU: #320934
Part: #TR5362CHW
UPC: 785007051230
20A 125V Hard Use Spec-Grade Tamper-Resistant Half-Controlled Plug Load Decorator Duplex Receptacle, White
SKU: #320934
Part: #TR5362CHW
UPC: 785007051230
Total Price: $12.69 per each Sold in increments of 1 each
Description
20A 125V Hard Use Spec-Grade Tamper-Resistant Half-Controlled Plug Load Decorator Duplex Receptacle, White - Plug Load Controllable Receptacle
This Pass & Seymour 20A 125V hard use spec-grade tamper-resistant half-controlled plug load decorator duplex receptacle is designed for reliable plug load control applications. It is suitable for electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers needing code-compliant controlled receptacles. The device allows for permanent controlled receptacle marking for easy identification and complies with NEC, CA Title 24, and ASHRAE Energy Efficiency Standard 90.1 requirements, ensuring energy efficiency in commercial spaces.
Specifications
- Manufacturer: Pass & Seymour
- Manufacturer Part #: TR5362CHW
- Voltage Rating: 125V
- Current Rating: 20A
- Number of Poles: Double Pole
- Color: White
- Finish: Matte
- Dimensions (W x H x L): 1.322 in x 2.635 in x 1.81 in
- Product Weight: 0.2 lbs
- Country of Origin: Mexico
- UPC: 785007051230
Features
- Permanent controlled markings on the face of the receptacle compliant with ASHRAE 90.1, CA Title 24, and NEC for clear identification
- Half-controlled design with welded, pre-wired lead controlling the top half of the receptacle for split-circuit applications
- Durable plated steel strap design for maximum durability and corrosion resistance
- .032 inch thick brass triple-wipe power contacts for lasting retention
- Auto-ground clip assures positive grounding
- Dual mechanical shutter system for tamper resistance and prevention of foreign object insertion
- PlugTail® built-in connector with large brass terminal contacts for consistent, reliable electrical connections
- Finger-safe design with no exposed terminals, eliminating the need for taping
- Meets all necessary code requirements for plug load control receptacles in commercial buildings
