Features

• This Ecologic Lamp Was Designed to Pass the Federal TCLP Criteria for Classification as Non-Hazardous Waste in Most States
• Mean Lumens are Measured at 40% of Average Rated Lamp Life
• Approximate Initial Lumens after 100 Hours Operation
• The Life Ratings of Fluorescent Lamps are Based on 3 Hour Operating Cycles Under Specified Conditions and with Ballast Meeting ANSI Specifications
• If Operating Cycle is Increased, there will be a Corresponding Increase in the Average Hours Life
• Lumen Output and Life Rated on High Frequency Operation
• Minimum Starting Temperature is a Function of the Ballast, Consult the Ballast Manufacturer
• There is a NEMA Supported, Industry Issue Where T2, T4 and T5 Fluorescent and Compact Fluorescent Lamps Operated on High Frequency Ballasts may Experience an Abnormal End-of-Life Phenomenon
• 95% Lumen Maintenance
• Greater Luminaire Design Flexibility
• QUICK 60+ System Warranty
• RoHS Compliant
• Lead-Free

Additional Information

• Mean Intensity 3069 Lumen at 25 Deg C/3394 Lumen at 35 Deg C
• Overall Dimension 0.63 Inch Diameter x 57.047 Inch Length
• Material Glass
• Application Cove and Valance, Direct/Indirect Luminaires, Facade Luminaire, Low Profile Surface Mount, Shallow Recessed Fixtures, Showcase, Signage
• Applicable Standard TCLP

Standards and Certifications

• Lead Free

Specifications

• Type: High Performance, Programmed Rapid Start
• Wattage: 35 Watt
• Shape Designation: T5
• Style: Pentron, Rare Earth Phosphor
• Base Type: Miniature Bi-Pin
• Initial Intensity: 3300 Lumen at 25 Deg C/3650 Lumen at 35 Deg C
• Color Rendering Index: 85
• Color Temperature in Kelvin: 3500
• Life in hour: 20000
• Nominal Length: 60 Inch
• Standard Package: 1 per Pack, 40 per Case
• Series/Model: FP35
