20025, Ground Bonding Pigtail
SKU: #282125
Part: #20025
UPC: 780321200258
20025, Ground Bonding Pigtail
SKU: #282125
Part: #20025
UPC: 780321200258
Next day delivery
Description
20025, Ground Bonding Pigtail – Electrical Grounding Solutions
The 20025 Ground Bonding Pigtail is designed for reliable grounding in residential, commercial, and industrial electrical installations. This product is used primarily for power distribution boxes, junction boxes, and multi-gang receptacle boxes to ensure secure grounding connections. It features a 12 AWG insulated stranded conductor with a captive GSH (Hex Head) ground screw and a flanged spade terminal for efficient and safe bonding. This grounding pigtail supports compliance with NEC standards and UL approval for both US and Canada, making it suitable for electrical distributors, lighting solutions providers, wire and cable suppliers, and switchgear suppliers.
Specifications
- Application: Residential, Commercial, Industrial
- Conductor Type: Insulated Stranded
- Conductor Size: 12 AWG
- Length: 12 Inch
- Color: Green
- Terminal Type: (1) Flanged Spade, Captive GSH Ground Screw
- Product Weight: 1.7 lbs
- Approval: UL Listed (Canada and US)
- Applicable Standard: NEC Articles 110.14 (A and B), 250.8 (A)
- Standard Package: 500 per Case
- Manufacturer: Engineered Products Company
- Manufacturer Part Number: 20025
Features
- Captive GSH Hex Head ground screw simplifies installation and ensures secure grounding to metal boxes.
- Pre-stripped conductor end for quick and reliable connection.
- Meets 2023 National Electrical Code requirements for grounding and bonding.
- UL Listed for safety and code compliance in both US and Canadian markets.
- Insulated stranded wire offers flexibility and durability in wiring applications.
- Color-coded green for easy identification of grounding conductor.
- Designed to save labor and installation time in power distribution and receptacle box grounding.
