Features

• Leviton’s line of Heavy-Duty Industrial Grade receptacles are available with a number of wiring options and features. The beauty, durability and versatility of Decora® devices and surge supression receptacles are perfect for a variety of industrial applications.
• Code Compliant - Allows you to increase the number of receptacles in your facility without having to pull new wires
• Durable - Impact and chemical resistant nylon cover and base
• Easy Installation - Termination anchor holes for easy conductor wiring
• Reliable - 10-Year Limited Warranty

NEMA

• 5-20R

Color Variations

• Brown

Specifications

• Country of Origin: Mexico
• RoHS Compliant: False

Standards and Certifications

• ANSI: C-73
• CSA C22.2 No. 42: File 152105
• NEMA: WD-1 WD-6
• NOM: 057
• UL498: File E13399
• Warranty: 10-Year Limited

Electrical Specifications

• Amperage: 20 A
• Current Limiting: Full Rated Current
• Dielectric Voltage: Withstands 2000V per UL498
• Grounding: Grounding
• Pole: 2
• Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
• Voltage: 125 VAC
• Wire: 3

AC Horsepower Ratings

• At Rated Voltage: 1 HP

Material Specifications

• Body Material: Nylon
• Color: White
• Cover Material: Nylon
• Grounding Screw: Plated Steel
• Line Contacts: Phosphor Bronze
• Strap Material: Galvanized Steel with Riveted Ground Contacts
• Terminal Screws: Plated Brass

Product Features

• Brand: 4-in-1
• Device Type: Quadruplex Receptacle Outlet
• Grade: Heavy-Duty Industrial Specification Grade

Environmental Specifications

• Flammability: Rated V-2 per UL 94
• Operating Temperature: -40°C to 60°C

Mechanical Specifications

• Product ID: Ratings are permanently marked on device
• Screw Terminal Torque: 10-12 in-lbs
• Terminal Accom.: 14-12 AWG
• Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
• Termination: Side Wire
• Torque Range: 12-14 inch pounds
