2" Top Flex II Tubing – Liquidtight Non-Metallic Tubing

The 2" Top Flex II Tubing by Southwire is a corrosion-resistant, non-metallic liquidtight conduit designed for protecting fiber optic and other sensitive cables. Ideal for use by electrical distributors and lighting solutions providers, this tubing connects EMT conduit to metal outlet boxes or enclosures where an offset is needed. It features a smooth interior to facilitate easy wire pulling and prevent conductor damage. Suitable for both interior and exterior applications, including automotive, computers, lab equipment, and laser environments, it supports high vibration conditions and is easily cut to length with standard tools.

Specifications

• Manufacturer Part #: HF22
• Size: 2"
• Ship Case Length: 50'
• Weight per Case: 60 lbs
• Outside Diameter: 2.340" – 2.375"
• Inside Diameter: 2.020" – 2.045"
• Wall Thickness: 0.33"
• Product Weight: 21.5 lbs

Features

• Resists corrosion, abrasion, oil, water, acid, metal shavings, and rough environments
• Integral rigid and flexible PVC construction
• Smooth interior surface for easy wire pulling and conductor protection
• Lightweight and strong for ease of handling and transport
• Suitable for high vibration applications
• Compatible with Top-Flex nylon, straight, or right angle connectors
• Usable in indoor and outdoor environments

Downloads & Links

• Spec Sheet
