2 1/2" EMT Set Screw Type Aluminum Conduit Bodies with Covers and Gaskets
SKU: #185179
Part: #ET7CG
UPC: 751338207462
2 1/2" EMT Set Screw Type Aluminum Conduit Bodies with Covers and Gaskets
SKU: #185179
Part: #ET7CG
UPC: 751338207462
Next day delivery
Description
2 1/2" EMT Set Screw Type Aluminum Conduit Bodies with Covers and Gaskets – Electrical Conduit Solutions
This 2 1/2" EMT set screw type aluminum conduit body by Southwire provides accessible wiring space for pulling, splicing, and maintenance in electrical installations. Designed for use by electrical distributors and lighting solutions providers, it features a roomy interior and smooth, rounded integral bushings to protect conductor insulation. The lightweight aluminum construction ensures excellent ground continuity and corrosion resistance, making it suitable for concrete applications. UL listed for safety and compliance.
Specifications
- Size: 2 1/2"
- Maximum Wire Size: 4/0 AWG
- Maximum Number of Conductors: 3
- Material: Copper-free aluminum die cast
- Cover Material: Stamped steel
- Gasket Material: Neoprene rubber
- Finish: Powder coat
- Product Weight: 5.25 lbs
- UL Standard: 514A
- Federal Specification: W-C-586D
- NEMA Standard: FB 1
Features
- Set screw T type design with cover and gasket for secure enclosure
- Roomy interior allows for maximum wiring space
- Smooth, rounded integral bushings protect conductor insulation
- Excellent ground continuity and corrosion resistance
- Lightweight aluminum construction for ease of handling
- Domed cover provides extra wiring space
- Suitable for use in concrete
- UL listed for safety and reliability
