1IN RISER GARD CORR ORG 500FT Flexible Raceways for Electrical Wiring

The 1IN RISER GARD CORR ORG 500FT is a corrugated, non-metallic flexible raceway designed for use in riser and general purpose applications, including vertical runs in shafts or between floors. Manufactured by Carlon, this PVC conduit features an orange color and is UL listed to UL 2024 standards, making it suitable for optical fiber, communications, and telecommunication cabling systems. It is available with factory pre-installed pull tape for ease of installation. This product is intended for indoor use and areas other than the plenum, meeting the requirements of the National Electrical Code (NEC) Articles 725, 770, 800, and 820. It is distributed by electrical distributors and supports lighting solutions, wire and cable management, and switchgear supplier needs.

Specifications

• Nominal Size: 1 in
• Material: PVC
• Color: Orange
• Length: 500 ft
• Outside Diameter: 1.32 in
• Inside Diameter: 0.98 in
• Wall Thickness: 0.060 in
• Pull Tape: Pre-installed
• UL Listing: UL 2024 (UL e151168)
• Application: Suitable for vertical runs in shafts, between floors, and areas other than the plenum
• Weight: 0.1400 lbs per ft

Features

• Non-metallic flexible raceway designed for riser and general purpose use
• UL Listed to UL 2024 standard for riser and optical fiber/communications raceways
• Factory pre-installed pull tape for ease of cable installation
• Meets NEC requirements for Articles 725, 770, 800, and 820
• Suitable for use in vertical runs within shafts and between floors
• Orange color enhances visibility for safety and identification
• Meets IPS outside diameter dimensions for compatibility
