1IN RISER GARD CORR ORG 1000FT Flexible Raceway

The 1IN RISER GARD CORR ORG 1000FT by Carlon is a non-metallic, flexible fiber optic corrugated conduit designed for riser and general purpose applications. It is suitable for use in vertical runs within shafts or between floors and other areas outside of the plenum. This product is UL listed to UL 2024 standards for riser and optical fiber/communications raceways, making it a reliable choice for electrical distributors and switchgear suppliers managing wire and cable installations in commercial and industrial environments.

Specifications

• Nominal Size: 1 inch
• Inside Diameter: 0.98 inch
• Outside Diameter: 1.32 inch
• Wall Thickness: 0.060 inch
• Length: 1000 ft
• Material: PVC
• Color: Orange
• Pull Tape: Factory pre-installed
• UL Listed to: UL 2024 Standard (e151168)
• Product Weight: 16.31 lbs (per 1000 ft reel)

Features

• Suitable for riser and general purpose areas per NEC Articles 725, 770, 800, and 820
• UL Listed raceway meeting UL 2024 for riser and communications applications
• Flexible corrugated design for ease of installation in vertical and horizontal runs
• Pre-installed pull tape facilitates cable pulling
• Meets IPS outside diameter dimensions for compatibility with standard fittings
• Not suitable for outdoor use due to lack of UV protection
• Storage temperature range: -4°F to 158°F; Handling temperature range: -4°F to 104°F
