18 Hr Wall Timer 60W 24-277V White Flash – Interval Wall Timer

The 18 Hr Wall Timer 60W 24-277V White Flash is an in-wall auto-off timer designed for precise interval control of electrical loads. Suitable for applications such as bathroom fans, indoor and outdoor lighting, and storage or hospitality areas, this timer supports voltages from 24 to 277 VAC at 50-60 Hz. It features a flicker warning function and is compatible with single-pole wiring, making it a practical solution for electrical distributors and lighting solutions providers seeking reliable timing control devices.

Specifications

• Input Voltage: 24/120/208-240/277 VAC, 50/60 Hz
• Timing Range: 1 minute to 18 hours
• Operating Temperature: 0 to 100 °F (-17 °C to 37 °C)
• Frequency: 50-60 hertz
• Action: SPST (Single Pole Single Throw)
• Wire Size: #18 AWG
• Product Weight: 0.4000 lbs
• Contact Ratings (Resistive Load): 0.50-7.25A
• Contact Ratings (Ballast Load): 0.50-7.25A*
• Contact Ratings (Tungsten Load): 0.50-4.0A
• Minimum Load: 12 Watts @ 24V, 60 Watts @ 120V, 105 Watts @ 208V, 120 Watts @ 240V, 150 Watts @ 277V
• Timing Accuracy: ±5% @ 60 °F to 80 °F
• Manufacturer Part Number: SS20F
• Color: White

Features

• Variable timing adjustable from 1 minute up to 18 hours
• Flash warning feature: load turns off for ½ second 2 minutes and 1 minute before end of timed cycle
• Tamper resistant: timer interval preset is hidden behind wall plate
• Easy setup with screwdriver adjustment for quick timing configuration
• No neutral wire required, simplifying retrofit installations
• Single-pole switch type compatible
