16262-IGW, 15 Amp Hospital Grade Receptacle

This Leviton hospital grade receptacle is designed for high-abuse tolerance applications, making it suitable for healthcare facilities, manufacturing plants, and schools. It provides reliable electrical connections and meets stringent UL testing standards, ensuring continuous and safe operation. Ideal for electrical distributors and lighting solutions requiring durable wire and cable components or switchgear supplier applications.

Specifications

• Amperage: 15 amperes
• NEMA: 5-15R
• Material: Nylon
• Color: White
• Grade: Hospital
• Grounding: Isolated Ground
• Dielectric: 2000 volts
• Number of Poles: 2
• Number of Wires: 3
• At Rated Voltage: 1/2 horse power
• Flammability Class: Rated V-2 Per UL94
• Operating Temperature: -40 To 60 degrees celsius
• ANSI Base: C-73
• Product Weight: 0.2570 lbs
• Manufacturer Part #: 16262-IGW

Features

• UL tested for continuous, safe operation in high-abuse environments
• Isolated ground for enhanced electrical safety
• Constructed with durable nylon material for long-lasting performance
• Designed specifically for hospital grade applications
