Description
Features
- Impact-resistant polycarb back body and frame.
- Cushioned thermoplastic paddle assures smooth, quiet, long term operation.
- Unique single rocking butterfly contact provides long term consistent performance with significantly fewer moving parts.
- Internal screw-pressure-plate back and side wire capability for easy installation with #14 - #10 stranded or solid copper/copper clad wire.
- Terminals made of high conductivity brass and serrated for maximum wire gripping.
- Silver alloy contacts integrally formed to the butterfly actuator assures reliable performance.
- Integral auto-ground clip for positive ground to metal boxes.
- Tri-drive ground, terminal, and mounting screws.
- All terminal screws backed out, ready-to-install.
- For covering patents, see
Certifications
- cULus Listed
- UL Listed
- CSA Listed
Specifications
- Depth: 1.06 in
- Height: 4.2 in
- Width: 1.3 in
- Country of Origin: Mexico
Specifications
- Color: White
- Product Line: Pass & Seymour
Downloads
Spec SheetSupporting Document
Commercial Switches HP Conversion TableCleaning Instructions for Wiring Devices
