130C-1X30FT Electrical Tape – High Voltage Rubber Splicing Tape

The 130C-1X30FT Electrical Tape by 3M is a premium-grade, linerless rubber splicing tape designed for insulating and terminating cables and wires. It is suitable for electrical distributors and lighting solutions requiring reliable wire and cable insulation. This tape withstands continuous operating temperatures up to 194°F (90°C) and emergency overloads up to 266°F (130°C), making it ideal for low- and high-voltage applications through 69 kV. Its self-fusing Ethylene Propylene Rubber (EPR) material offers excellent electrical and mechanical properties, providing a moisture-tight seal and stable, durable splices.

Specifications

• Material: Ethylene Propylene Rubber (EPR)
• Finish: Black
• Width: 1 Inch
• Length: 30 Foot
• Thickness: 30 mil
• Operating Temperature: Up to 194°F (90°C)
• Emergency Overload Temperature: Up to 266°F (130°C)
• Elongation: 850%
• Breaking Strength: 7.5 lbs/in
• Tape Grade: Premium
• Tape Type: Insulating and Splicing
• RoHS Compliant: Yes
• Manufacturer: 3M
• Manufacturer Part #: 130C-1X30FT
• Country of Origin: USA

Features

• Linerless, self-fusing design for fast and efficient installation
• Excellent thermal dissipation for stable, long-lasting splices
• Highly conformable to irregularly shaped objects
• Provides immediate moisture seal and void-free buildup
• Suitable for insulating bus bars, motor leads, and end sealing high-voltage cables
• Rated for continuous operation and emergency overloads in demanding electrical environments
