Specifications

Material Specifications

• Outer Enclosure: Powder Coated Steel

Warranty

• Warranty: 5-Year Limited
• Connected Equipment Coverage: Up to $25,000

Product Features

• Replaceable Modules: No
• Country Of Origin: Mexico

Standards and Certifications

• ANSI/IEEE Category A, B & C: C-62.41 & 62.45
• UL 1449 4th Edition: cULus Listed Type 2

Performance Data

• Nominal Discharge Current Rating: 3kA
• Short Circuit Current Rating: 10kA
• MCOV L-L: 300
• MCOV L-N: 150
• VPR L-L: 1200
• VPR L-N: 800
• Maximum Surge Current, Per Mode (Per Phase): SOkA (100kA)

Mechanical Specifications

• Diagnostics: Protection Status LEDs
• Surge Counter: No
• Connection Type: Parallel - Hardwired via 12 AWG Wire

Electrical Specifications

• Frequency: 50/60Hz
• Recommended Circuit Breaker Rating: 20A, 120/208V
• EMI/RFI Noise Rejection: (-6 to -28dB @ 100KHz to 100MHz)
• Voltage Configuration: 120/208 V, 3-Phase WYE
• Surge Technology: 40mm MOV Design

Environmental Specifications

• Flammability: Rated V-2 per UL 94
• Operating Temperature: -10°C to 60°C
• Enclosure: Type 1
• Relative Humidity: 5% to 95% non-condensing
• Storage Temperature Range: -20C to 85C
