1-1/4" Rigid Offset Nipples, 3/4" Offset HDG - Malleable Iron Conduit Fitting

This 1-1/4" rigid offset nipple is designed for use in electrical conduit systems to provide a 3/4" offset between two enclosures or raceways. Manufactured from malleable iron with a hot dip galvanized finish, it is suitable for both indoor and outdoor applications. The nipple features threaded 1-1/4 NPSM connections and a smooth interior surface to facilitate wire pulling without damage. It is ideal for electrical distributors, lighting solutions, wire and cable installations, and switchgear suppliers requiring durable conduit fittings that maintain system integrity.

Specifications

• Material: Malleable Iron
• Finish: Hot Dip Galvanized
• Connection: 1-1/4 NPSM IN Threaded
• Length: 3.13 IN
• Outside Diameter: 2 IN
• Flexibility: Rigid Conduit
• Product Weight: 0.5850 lbs
• Application: Indoor, Outdoor, Use as an Offset Connector between Two Enclosures, Raceways

Features

• 3/4" offset to change conduit direction or elevation
• Hot dip galvanized coating for corrosion resistance
• Threaded connection for secure installation
• Smooth interior surface to facilitate wire pulling and prevent abrasion
