1-1/4 in. Conduit Body Type E
SKU: #152101
Part: #5133154
UPC: 088700065345
1-1/4 in. Conduit Body Type E
SKU: #152101
Part: #5133154
UPC: 088700065345
Description
1-1/4 in. Conduit Body Type E – Electrical Conduit Fitting
The CANTEX 1-1/4 in. Conduit Body Type E is designed to provide pull, splice, and tap access for conductors within a conduit system. This conduit body is suitable for electrical distributors and switchgear suppliers requiring reliable wiring access points in conduit installations. It is commonly used in wire and cable management for lighting solutions and electrical distribution applications.
Specifications
- Manufacturer: Cantex
- Manufacturer Part #: 5133154
- Product Weight: 18.6 lbs
- Size: 1-1/4 inch
- Carton Quantity: 10
- UPC: 088700065345
- Volume: 25 cubic inches (from technical drawing)
- Dimensions (Nominal, from technical drawing):
- "A": 2 7/16 in.
- "B": 2 7/16 in.
- "C": 7 5/8 in.
- "D": 7 3/16 in.
- "E": 1 5/8 in.
Features
- Provides easy pull, splice, and tap access for conductors in conduit systems
- Constructed from PVC, offering durability and resistance to corrosion
- Compatible with PVC conduit for electrical wire and cable installations
- Stable material with no hazardous polymerization
- Meets safety requirements for electrical distributors and switchgear suppliers
