Description
Features
- Smooth, Rounded Integral Bushings in Hubs Protect Conductor Insulation
- Accurately Tapped, Tapered Threads for Tight, Rigid Joints and Excellent Ground Continuity
- Unique Wedge-Lok™ Clip Cover Design Allows Easy Removal at any Later Time, without Damaging the Conduit Body
- The Cover is Secured with Clips, Not Screws
- Smooth Hub Bushings and Cover Openings Protect Conductor Insulation
- Smooth Hub Openings Allow Easy Conduit Joining
Additional Information
- Maximum Wire Fill (3) 2 AWG
- Applicable Standard NEMA FB-1/FB-2.10, Federal Specification A-A-50563
Specifications
- Access Opening: Right Side
- Configuration: LR
- Cover Type: Zinc Electroplated/Chromate/Epoxy Powder Coated Grayloy Iron
- Hub Location: 90 Degree
- Number of Hubs: 2
- Hub Size: 2 Inch
- Size: 8.13 Inch L x 4.06 Inch W x 4.25 Inch H
- Installation: Threaded
- Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Gray Iron
- Form Type: Form 7
- Approval: UL, UL 514A, CSA C22.2
- Used On: Rigid/IMC Conduit
Downloads
CatalogOther 1
More Information
Manufacturer Catalog Number
LR67
Weight
4.7750
Length
8-1/8 IN
Width
4-1/8 IN
Height
3-1/8 IN
Material
Iron
Color
Gray
Finish
Zinc Electroplated With Aluminum Enamel
Product Size
4.06 inches
Type
Type LR Conduit Body
