Features

• Pulls 5/16-Inch to 3/4-Inch steel cables
• For use on guy strand and EHS cable sizes from 0.3 to 0.8 inches (8 - 20 mm)
• Sawtooth jaw profile resists build-up from galvanized coating on guy strand and EHS cables and spring helps maintain cable position in grips jaw
• 5-Inch (127 mm) jaw length increases surface area contact with the cable
• Made in USA
• Round Inside-jaw Contour

Warnings

• Before each use, clean jaw area and inspect grip for proper operation to avoid slippage.
• When used on/near energized lines, ground, insulate, or isolate grip before pulling.
• Do not exceed rated capacity.

Specifications

• Cable Type: Guy Strand, EHS, Coated
• Type: Parallel Jaw Grip
• Application: Wire Pulling
• Cable Diameter: 0.3" to 0.8" (7.62 to 20.3 mm)
• Jaw Type: Round - Serrated
• Jaw Length: 5" (12.7 cm)
• Overall Length: 11.365" (28.9 cm)
• Maximum Safe Load: 10,000 lb (4536 kg)
• Hot Latch: No
• Spring: Yes
• Locking Handle: No
• Swing Latch: No
• Height: 2.0150 in
• Width: 6.4330 in
• Depth: 11.3650 in
• Weight: 7.0000 lbs
