Features

• Contemporary Bar-Stock Grille Designed to Provide Optimized Airflow
• Manual Reset Thermal Overheat Protector Disconnects Power in the Event of Accidental Blockage
• Built-In Tamper Resistant Thermostat
• All Units have a Permanently Lubricated Enclosed Fan Motor, Which Creates Long Life, Low Maintenance and Gently Distributes Warmth Throughout the Area
• Automatic Fan Delay Eliminates Cold Drafts on Start-Up and Discharges Residual Heat from the Heater Body During Shut Down
• Power On/Off Switch for Added Safety During Maintenance

Additional Information

• Grille Material Satin Aluminum Grille (Front), 16 Gauge Cold Rolled Steel
• Size 15-3/4 Inch Width x 1-1/4 Inch Depth x 19-5/16 Inch Height
• Wire Size 10 and 12 AWG
• Temperature Rating 40 to 90 Deg F

Specifications

• Type: Heavy Duty, Architectural
• Voltage Rating: 208/240 Volt AC
• Current Rating: 7.2/14.4 Amp at 208 Volt AC, 8.3/16.7 Amp at 240 Volt AC
• Power Rating: 1500/3000 Watt at 208 Volt AC, 2000/4000 Watt at 240 Volt AC
• Number of Phases: 1
• Heating Capacity: 5118/10236 BTU/Hour at 208 Volt AC, 6824/13649 BTU/Hour at 240 Volt AC
• Housing Size: 15-3/4 Inch Width x 3-7/8 Inch Depth x 19-5/16 Inch Height
• Material: 20 Gauge Steel
• Finish: Galvanized
• Color: Bronze
• Heating Element: Non-Glowing, Copper Brazed Finned Sheathed Steel
• Control Type: Built-In Thermostat, Thermal Cutout
• Fan/Motor Type: 5-Bladed Aluminum Enclosed
• Air Flow Rate: 100 CFM
• Mounting: Recessed Wall/Surface
• Application: Entrance Way, Lobbie, Hallway, Stairwell, Restaurant, Conference Room, Office, Basement, Family Room
• Approval: ETL (Canada and US), CSA C22.2, ANSI/UL2021
• Series/Model: AWH
